HAES Esento Eclipse 2 Zone Conventional / Twin Wire Fire Panel (ECL-2)
SKU
ECL-2
£190.72 £158.93
HAES Esento Eclipse 2 Zone Conventional / Twin Wire Fire Alarm Control Panel (ECL-2)
Product Details for HAES Esento Eclipse 2 Zone Conventional / Twin Wire Fire Panel (ECL-2)
The HAES ECL-2 Esento Eclipse is a 2 zone Conventional / Twin Wire (sav-wire) control panel with integral power supply and space for standby batteries.
Two fire zone circuits are provided plus two monitored sounder circuits. Fire & Fault VFCO relays, Fire & Fault switched negative outputs, class change and an alert input are also included. The fire zone outputs can be set as ‘Twin Wire’ by DIL switch selection. In ‘Twin Wire’ configuration, sav-wire detector bases and call points must be used.
HAES Eclipse panels support a large range of conventional detectors including Apollo, Hochiki & Nittan.
The panels are supplied with a 1.25 amp internal power supply module. This module complies with the requirements of EN54-4 : 1988 and provides temperature-compensated battery management charging.
Eclipse panels are fully approved to European standards EN54-2 & 4, Fire Detection and Alarm Systems – Control & Indicating Equipment.
Key Features of the ECL-2 |
|---|
| > False alarm management mode > Twin Wire selection by DIL switch > Approved to EN54-2 & 4 > Fire and fault relays > One man walk test > Non latching zones > Class change inputs > 3 year warranty |
| Brand | HAES Technologies |
|---|---|
| Manufacturer Part No. | ECL-2 |
| Product Series | Esento |
| Primary Power Source | Mains Powered (230V) |
| System Type | Conventional/2-Wire |
| Number of Zones | 2 |
| Colour | Grey |
| Warranty | 3 Years |
Write Your Own Review
FAQ’s for HAES Esento Eclipse 2 Zone Conventional / Twin Wire Fire Panel (ECL-2)
No questions yet. Be the first to ask the question!
Product Specification for HAES Esento Eclipse 2 Zone Conventional / Twin Wire Fire Panel (ECL-2)
| Enclosure | 1.2mm Mild Steel IP30. Colour ref: MW334E Interpon powder coat |
| Cable Entry | Via 20mm knockouts located in the top and rear of the cabinet |
| Dimensions | Back box: 300mm W x 250mm H x 80mm D, Lid: 308mm W x 260mm H x 23mm D |
| Mains Supply | 1.25A internal switch mode power supply, Nom 27v DC |
| Battery Capacity | 2 x 3.2Ah 12v VRSLA |
| Detection Zones | 2 x conventional or Twin Wire. EOL = 4K7R |
| Sounder Circuits | 2 x monitored, fused @500mA. EOL = 4K7R |
| Twin Wire | Selectable in panel |
| On Board Relays | 1 x Fire, 1 x Fault, 3A, 30v volt free changeover |
| Outputs | 1 x Fire, 1 x Fault 40mA switch -ve outputs |
| Switch Inputs | Class change & alert (pulsing) |
| Intrinsically Safe Mode | Selectable per zone |
| False Alarm Management | Type A dependency mode, approved by LPCB |
