HAES Esento Evoque 24 Zone Conventional Fire Alarm Panel (XL32-24)
SKU
XL32-24
£1,064.58 £887.15
HAES Esento Evoque 24 Zone Conventional Fire Alarm Panel (XL32-24)
Product Details for HAES Esento Evoque 24 Zone Conventional Fire Alarm Panel (XL32-24)
The HAES XL32-24 Esento Evoque panel provides 24 Conventional fire detection zones. All inputs and outputs are fully programmable and there are options to have delays to the outputs. The programming features also include 3 different modes to help reduce false alarms.
As standard, all Evoque panels provide four monitored sounder circuits, Fire & Fault VFCO relays, Fire, Fault, Reset & Disablement switched negative outputs, Class Change, Alert, Silence & Reset inputs.
A fully functional repeater panel is available via a plug-in comms PCB. Evoque panels support a large range of conventional detectors including Apollo, Hochiki & Nittan.
The panels are supplied with a 5.0 amp internal power supply module. This module complies with the requirements of EN54-4: 1988 and provides temperature compensated battery management charging.
Evoque panels are approved to European standards EN54-2 & 4, Fire Detection and Alarm Systems – Control & Indicating Equipment.
Key Features of the XL32-24 |
|---|
| > 24 conventional fire detection zones > Network up to 8 control panels > Activate controls via key switch or code entry > Integral detector removal monitoring > 5 Amp switch mode power supply Nom 27V DC > 4 monitored sounder outputs > 2 Aux C/O relays (1 x Fire) (1 x Fault). voltage free > Class Change, Alert, Silence Alarms & Reset switched -ve inputs > Fire, Fault, Disablement & Reset, programmable switched -ve outputs > Program delays to outputs > False alarm modes A, B & C > Test mode, with or without sounders > Disable zones, sounder O/Ps, aux O/Ps & delays > Fire alarm routing output programmable option > Alarm load, 4.25A shared between all sounder outputs > All sounder circuits are fused @ 500mA with resettable fuses |
| Brand | HAES Technologies |
|---|---|
| Manufacturer Part No. | XL32-24 |
| Product Series | Esento |
| Primary Power Source | Mains Powered (230V) |
| System Type | Conventional |
| Number of Zones | 24 |
| Colour | Grey |
| Warranty | 3 Years |
Write Your Own Review
FAQ’s for HAES Esento Evoque 24 Zone Conventional Fire Alarm Panel (XL32-24)
No questions yet. Be the first to ask the question!
Product Specification for HAES Esento Evoque 24 Zone Conventional Fire Alarm Panel (XL32-24)
| Enclosure | 1.2mm Mild Steel IP30. Colour ref: MW334E Interpon powder coat |
| Cable Entry | Via 20mm knockouts located in the top and rear of the cabinet |
| Dimensions | Back box: 450mm W x 400mm H x 130mm D, Lid: 465mm W x 410mm H x 25mm D |
| Mains Supply | 5A internal switch mode power supply, Nom 27v DC |
| Battery Capacity | 2 x 18Ah 12v VRSLA |
| Detection Zones | 24 x conventional. EOL = 4K7 |
| Sounder Circuits | 4 x monitored, fused @500mA. EOL = 4K7 |
| Networking | Up to 8 control panels, fault tolerant RS485 communication, requires TPCA05 network card |
| On Board Relays | 2 x programmable, 3A, 30v volt free changeover |
| Programmable Outputs | 4 x programmable 40mA switch -ve outputs |
| Switch Inputs | Class change, alert (pulsing), silence alarms & reset |
| Event Log | 40 event history |
| Intrinsically Safe Mode | Selectable per zone |
| False Alarm Management | Type A, B & C dependency modes, approved by LPCB |
| Delay Timer | On board programmable delay timer 1-10 mins |
